Sliding system for shutters WIN-SLIDE 2

Capacity per panel: 80 kg
Panel thickness: 25-40 mm (up to 80 mm (1 channel) for a "shade screen" type mounting)
Panel types: Wood, Aluminium, PVC,etc.
Track: Anodised aluminium
Movement: Straight

WIN-SLIDE 2 high-end sliding systems.

COMPACT: reduced vertical space requirements across the range, with 3-directional adjustment maintained. The brackets have diagonal oblong holes for more stability. New compact pelmet - return pulley integrated into the end stop.
TIME-SAVING: spacing between track fastening points increased by 50% (from 44 to 66 cm)
SAFETY: new end stop with 2 anchoring points in the track
INNOVATION: new damper ensuring panels open and close softly.

The new hanger rollers increase the surface area of the panel exposed to wind
